CIS x 2 LED 600 x 600 dpi

80 ppm/ 160 ipm (Grayscale/B&W mode, 200 dpi, A4 Portrait)

80 ppm/ 160 ipm (Grayscale/B&W mode, 300 dpi, A4 Portrait)

45 ppm/ 90 ipm (Color mode, 200 dpi, A4 Portrait)

30 ppm/ 60 ipm (Color mode, 300 dpi, A4 Portrait)

w/ ISIS,TWAIN,ABBY

Image Sensor CIS x 2 (Duplex Scanner)

Light Source LED

Optical Resolution 600 dpi

Interpolated Resolution 1,200 dpi

Hardware Resolution 600 x 1200 dpi

Scan Modes Color: 48-bit input, 24-bit output

Grayscale: 16-bit input, 8-bit output

B/W: 1-bit

ADF Capacity 1. 100 sheets (A4/ Letter, 80 g/㎡ or 20 Lbs)

2. 30 sheets (Business Cards)

3. Plastic Card, Max. thickness under 1.2 mm.

Note: Maximum ADF capacity varies, depending upon paper weight.

Scanning Speed ( ADF ) 80 ppm/ 160 ipm (Grayscale/B&W mode, 200 dpi, A4 Portrait)

80 ppm/ 160 ipm (Grayscale/B&W mode, 300 dpi, A4 Portrait)

45 ppm/ 90 ipm (Color mode, 200 dpi, A4 Portrait)

30 ppm/ 60 ipm (Color mode, 300 dpi, A4 Portrait)

Note: Results may vary depending upon your scanning application, computer processor and system memory.

Scanning Area (W x L) Max: 216 x 5080 mm

Min: 13.2 x 13.2 mm

Acceptable Paper Sizes (W x L) Max: 216 x 5080 mm

Min: 50.8 x 50.8 mm

Acceptable Paper Weight (Thickness) 40 to 220 g/㎡ (10 to 58 Lbs)

Multi-feed Detection With ultrasonic technology

Daily Duty Scan ( Sheets ) 8,000

Roller Lifetime (Scans) 300,000

Pad Lifetime (Scans) 100,000

Action Button 4 Buttons: Up, Down, Scan, Standby

9 function keys are all customizable.

Power Supply 24 Vdc/ 0.75 A

Interface USB 2.0 Type B x 1

Net Weight 2.7 kg

Dimensions (W x D x H) 318.7 x 230.7 x 228.3 mm

Protocol TWAIN Compliant

Operating System Windows XP / Vista / 7 / 8 / 10 / 11

macOS 10.12.x/ 10.13.x/ 10.14.x/ 10.15.x/ 11.x/ 12.x/ 13.x/ 14.x/ 15.x/ 26.x

Linux compatibility is only available for system integrators. Please contact sales@plustek.com for more info.

Hardware Requirements Windows and Mac

3.2 GHz CPU processor or higher[1]

[1]Windows Recommended: 3.2 GHz Intel® Core™ i7 Processor with 4 CPU Cores or higher

4 GB RAM minimum (Recommended: 8 GB or more)

6 GB of hard-disk space for program installation

Display dimensions of 1024x768 or greater

Bundled Software Plustek DocAction Plus

Plustek DocTWAIN

Plustek MacAction

Plustek ICA

Built-in OCR Plustek OCR (For Windows)

(Powered by ABBYY® FineReader®)

Plustek DocOCR (For Mac)
